产品认证:原料UL.欧洲CE,欧洲环保RoHS,REACH。
防火等级:UL94V-0,低烟无卤,遇火不燃烧,防火性及绝缘性特佳。
产品构造:由槽底及槽盖组成。
颜 色:灰色.乳白色.蓝色,浅灰色
工作温度 :静态-40°C持续高温至110°C。
*无卤原料采用PC+ABS制成。
产品用途：半导体制造,造船,核能发电厂，石油平台，电梯，机车及地铁，风能发电平台，温度及环境恶劣等行业。
更多选择:可按需求生产定制其它长度.
无卤线槽以槽盖槽底组合后外部宽高为准
表格如没有你所需要的规格，我司可以开发设计供应！
| 型号Item No. | 宽*高 W*H | 孔宽 Q | 齿宽 P | 装箱 /M | |||
| 灰色Gray | 乳白色White | 蓝色Blue | 黑色Black | ||||
| VDR1616F/HF | VDR1616FW/HF | VDR1616FE/HF | VDR1616FB/HF | 16*16 | 8 | 10 | 300M |
| VDR2516F/HF | VDR2516FW/HF | VDR2516FE/HF | VDR2516FB/HF | 25*16 | 8 | 10 | 260M |
| VDR1520F/HF | VDR1520FW/HF | VDR1520FE/HF | VDR1520FB/HF | 15*20 | 8.5 | 12 | 260M |
| VDR2020F/HF | VDR2020FW/HF | VDR2020FE/HF | VDR2020FB/HF | 20*20 | 8.5 | 12 | 240M |
| VDR4020F/HF | VDR4020FW/HF | VDR4020FE/HF | VDR4020FB/HF | 40*20 | 8 | 12 | 140M |
| VDR1525F/HF | VDR1525FW/HF | VDR1525FE/HF | VDR1525FB/HF | 15*25 | 8 | 12 | 260M |
| VDR2025F/HF | VDR2025FW/HF | VDR2025FE/HF | VDR2025FB/HF | 20*25 | 8 | 12 | 200M |
| VDR2525F/HF | VDR2525FW/HF | VDR2525FE/HF | VDR2525FB/HF | 25*25 | 8 | 12 | 200M |
| VDR3025F/HF | VDR3025FW/HF | VDR3025FE/HF | VDR3025FB/HF | 30*25 | 8 | 12 | 160M |
| VDR4025F/HF | VDR4025FW/HF | VDR4025FE/HF | VDR4025FB/HF | 40*25 | 8 | 12 | 100M |
| VDR5025F/HF | VDR5025FW/HF | VDR5025EF/HF | VDR5025FB/HF | 50*25 | 8 | 12 | 100M |
| VDR1530F/HF | VDR1530FW/HF | VDR1530FE/HF | VDR1530FB/HF | 15*30 | 8 | 12 | 180M |
| VDR2030F/HF | VDR2030FW/HF | VDR2030FE/HF | VDR2030FB/HF | 20*30 | 8 | 12 | 130M |
| VDR2530F/HF | VDR2530FW/HF | VDR2530FE/HF | VDR2530FB/HF | 25*30 | 8 | 12 | 130M |
| VDR3030F/HF | VDR3030FW/HF | VDR3030FE/HF | VDR3030FB/HF | 30*30 | 8 | 12 | 140M |
| VDR4030F/HF | VDR4030FW/HF | VDR4030FE/HF | VDR4030FB/HF | 40*30 | 8 | 12 | 100M |
| VDR5030F/HF | VDR5030FW/HF | VDR5030FE/HF | VDR5030FB/HF | 50*30 | 8 | 12 | 80M |
| VDR6030F/HF | VDR6030FW/HF | VDR6030FE/HF | VDR6030FB/HF | 60*30 | 8 | 12 | 60M |
| VDR2233F/HF | VDR2233FW/HF | VDR2233FE/HF | VDR2233FB/HF | 22*33 | 8 | 12 | 160M |
| VDR3333F/HF | VDR3333FW/HF | VDR3333FE/HF | VDR3333FB/HF | 33*33 | 8 | 12 | 160M |
| VDR2035F/HF | VDR2035FW/HF | VDR2035FE/HF | VDR2035FB/HF | 20*35 | 8 | 12 | 100M |
| VDR3535F/HF | VDR3535FW/HF | VDR3535FE/HF | VDR3535FB/HF | 35*35 | 8 | 12 | 112M |
| VDR5035F/HF | VDR5035FW/HF | VDR5035FE/HF | VDR5035FB/HF | 50*35 | 8 | 12 | 88M |
| VDR2040F/HF | VDR2040FW/HF | VDR2040FE/HF | VDR2040FB/HF | 20*40 | 8 | 12 | 110M |
| VDR2540F/HF | VDR2540FW/HF | VDR2540FE/HF | VDR2540FB/HF | 25*40 | 8 | 12 | 112M |
| VDR3540F/HF | VDR3540FW/HF | VDR3540FE/HF | VDR3540FB/HF | 35*40 | 8 | 12 | 100M |
| VDR4040F/HF | VDR4040FW/HF | VDR4040FE/HF | VDR4040FB/HF | 40*40 | 8 | 12 | 100M |
| VDR6040F/HF | VDR6040FW/HF | VDR6040FE/HF | VDR6040FB/HF | 60*40 | 8 | 12 | 68M |
| VDR8040F/HF | VDR8040FW/HF | VDR8040FE/HF | VDR8040FB/HF | 80*40 | 8 | 12 | 48M |
| VDR10040F/HF | VDR10040FW/HF | VDR10040FE/HF | VDR10040FB/HF | 100*40 | 8 | 12 | 32M |
| VDR12040F/HF | VDR12040FW/HF | VDR12040FE/HF | VDR12040FB/HF | 100*40 | 8 | 12 | / |
| VDR2545F/HF | VDR2545FW/HF | VDR2545FE/HF | VDR2545FB/HF | 25*45 | 8 | 12 | 104M |
| VDR3345F/HF | VDR3345FW/HF | VDR3345FE/HF | VDR3345FB/HF | 33*45 | 8 | 12 | 108M |
| VDR4545F/HF | VDR4545FW/HF | VDR4545FE/HF | VDR4545FB/HF | 45*45 | 8 | 12 | 72M |
| VDR6545F/HF | VDR6545FW/HF | VDR6545FE/HF | VDR6545FB/HF | 65*45 | 8 | 12 | 56M |
| VDR2050F/HF | VDR2050FW/HF | VDR2050FE/HF | VDR2050FB/HF | 20*50 | 8 | 12 | 100M |
| VDR2550F/HF | VDR2550FW/HF | VDR2550FE/HF | VDR2550FB/HF | 25*50 | 8 | 12 | 100M |
| VDR3050F/HF | VDR3050FW/HF | VDR3050FE/HF | VDR3050FB/HF | 30*50 | 8 | 12 | 84M |
| VDR3550F/HF | VDR3550FW/HF | VDR3550FE/HF | VDR3550FB/HF | 35*50 | 8 | 12 | 80M |
| VDR4050F/HF | VDR4050FW/HF | VDR4050FE/HF | VDR4050FB/HF | 40*50 | 8 | 12 | 68M |
| VDR4550F/HF | VDR4550FW/HF | VDR4550FE/HF | VDR4550FB/HF | 45*50 | 8 | 12 | 60M |
| VDR5050F/HF | VDR5050FW/HF | VDR5050FE/HF | VDR5050FB/HF | 50*50 | 8 | 12 | 50M |
| VDR5550F/HF | VDR5550FW/HF | VDR5550FE/HF | VDR5550FB/HF | 55*50 | 8 | 12 | 48M |
| VDR6050F/HF | VDR6050FW/HF | VDR6050FE/HF | VDR6050FB/HF | 60*50 | 8 | 12 | 48M |
| VDR7550F/HF | VDR7550FW/HF | VDR7550FE/HF | VDR7550FB/HF | 75*50 | 8 | 12 | 40M |
| VDR8050F/HF | VDR8050FW/HF | VDR8050FE/HF | VDR8050FB/HF | 80*50 | 8 | 12 | 40M |
| VDR10050F/HF | VDR10050FW/HF | VDR10050FE/HF | VDR10050FB/HF | 100*50 | 8 | 12 | 26M |
| VDR12555F/HF | VDR12555FW/HF | VDR12555FE/HF | VDR12555FB/HF | 125*55 | 8 | 12 | 26M |
| VDR2060F/HF | VDR2060FW/HF | VDR2060FE/HF | VDR2060FB/HF | 20*60 | 8 | 12 | 100M |
| VDR2560F/HF | VDR2560FW/HF | VDR2560FE/HF | VDR2560FB/HF | 25*60 | 8 | 12 | 100M |
| VDR3060F/HF | VDR3060FW/HF | VDR3060FE/HF | VDR3060FB/HF | 30*60 | 8 | 12 | 80M |
| VDR3560F/HF | VDR3560FW/HF | VDR3560FE/HF | VDR3560FB/HF | 35*60 | 8 | 12 | 78M |
| VDR4060F/HF | VDR4060FW/HF | VDR4060FE/HF | VDR4060FB/HF | 40*60 | 8 | 12 | 60M |
| VDR4560F/HF | VDR4560FW/HF | VDR4560FE/HF | VDR4560FB/HF | 45*60 | 8 | 12 | 30M |
| VDR5060F/HF | VDR5060FW/HF | VDR5060FE/HF | VDR5060FB/HF | 50*60 | 8 | 12 | 60M |
| VDR6060F/HF | VDR6060FW/HF | VDR6060FE/HF | VDR6060FB/HF | 60*60 | 8 | 12 | 48M |
| VDR8060F/HF | VDR8060FW/HF | VDR8060FE/HF | VDR8060FB/HF | 80*60 | 8 | 12 | 36M |
| VDR10060F/HF | VDR10060FW/HF | VDR10060FE/HF | VDR10060FB/HF | 100*60 | 8 | 12 | 28M |
| VDR11060F/HF | VDR11060FW/HF | VDR11060FE/HF | VDR11060FB/HF | 110*60 | 8 | 12 | 48M |
| VDR12060F/HF | VDR12060FW/HF | VDR12060FE/HF | VDR12060FB/HF | 120*60 | 8 | 12 | 48M |
| VDR15060F/HF | VDR15060FW/HF | VDR15060FE/HF | VDR15060FB/HF | 150*60 | 8 | 12 | 16M |
| VDR2565F/HF | VDR2565FW/HF | VDR2565FE/HF | VDR2565FB/HF | 25*65 | 8 | 12 | 88M |
| VDR3365F/HF | VDR3365FW/HF | VDR3365FE/HF | VDR3365FB/HF | 33*65 | 8 | 12 | 80M |
| VDR4565F/HF | VDR4565FW/HF | VDR4565FE/HF | VDR4565FB/HF | 45*65 | 8 | 12 | 52M |
| VDR6565F/HF | VDR6565FW/HF | VDR6565FE/HF | VDR6565FB/HF | 65*65 | 8 | 12 | 44M |
| VDR7265F/HF | VDR7265FW/HF | VDR7265FE/HF | VDR7265FB/HF | 72*65 | 8 | 12 | 42M |
| VDR2575F/HF | VDR2575FW/HF | VDR2575FE/HF | VDR2575FB/HF | 25*75 | 8 | 12 | / |
| VDR5075F/HF | VDR5075FW/HF | VDR5075FE/HF | VDR5075FB/HF | 50*75 | 8 | 12 | 42M |
| VDR7575F/HF | VDR7575FW/HF | VDR7575FE/HF | VDR7575FB/HF | 75*75 | 8 | 12 | 40M |
| VDR10075F/HF | VDR10075FW/HF | VDR10075FE/HF | VDR10075FB/HF | 100*75 | 8 | 12 | 24M |
| VDR2580F/HF | VDR2580FW/HF | VDR2580FE/HF | VDR2580FB/HF | 25*80 | 8 | 12 | 72M |
| VDR3080F/HF | VDR3080FW/HF | VDR3080FE/HF | VDR3080FB/HF | 30*80 | 8 | 12 | 56M |
| VDR3580F/HF | VDR3580FW/HF | VDR3580FE/HF | VDR3580FB/HF | 35*80 | 8 | 12 | 56M |
| VDR4080F/HF | VDR4080FW/HF | VDR4080FE/HF | VDR4080FB/HF | 40*80 | 8 | 12 | 48M |
| VDR4580F/HF | VDR4580FW/HF | VDR4580FE/HF | VDR4580FB/HF | 45*80 | 8 | 12 | 40M |
| VDR5080F/HF | VDR5080FW/HF | VDR5080FE/HF | VDR5080FB/HF | 50*80 | 8 | 12 | 40M |
| VDR5580F/HF | VDR5580FW/HF | VDR5580FE/HF | VDR5580FB/HF | 55*80 | 8 | 12 | 32M |
| VDR6080F/HF | VDR6080FW/HF | VDR6080FE/HF | VDR6080FB/HF | 60*80 | 8 | 12 | 32M |
| VDR8080F/HF | VDR8080FW/HF | VDR8080FE/HF | VDR8080FB/HF | 80*80 | 8 | 12 | 24M |
| VDR10080F/HF | VDR10080FW/HF | VDR10080FE/HF | VDR10080FB/HF | 100*80 | 8 | 12 | 24M |
| VDR12080F/HF | VDR12080FW/HF | VDR12080FE/HF | VDR12080FB/HF | 120*80 | 8 | 12 | 16M |
| VDR14080F/HF | VDR14080FW/HF | VDR14080FE/HF | VDR14080FB/HF | 140*80 | 8 | 12 | 16M |
| VDR16080F/HF | VDR16080FW/HF | VDR16080FE/HF | VDR16080FB/HF | 160*80 | 8 | 12 | / |
| VDR25100F/HF | VDR25100FW/HF | VDR25100FE/HF | VDR25100FB/HF | 25*100 | 8 | 12 | 60M |
| VDR33100F/HF | VDR33100FW/HF | VDR33100FE/HF | VDR33100FB/HF | 33*100 | 8 | 12 | 44M |
| VDR40100F/HF | VDR40100FW/HF | VDR40100FE/HF | VDR40100FB/HF | 40*100 | 8 | 12 | 40M |
| VDR50100F/HF | VDR50100FW/HF | VDR50100FE/HF | VDR50100FB/HF | 50*100 | 8 | 12 | 40M |
| VDR60100F/HF | VDR60100FW/HF | VDR60100FE/HF | VDR60100FB/HF | 60*100 | 8 | 12 | 32M |
| VDR70100F/HF | VDR70100FW/HF | VDR70100FE/HF | VDR70100FB/HF | 70*100 | 8 | 12 | 24M |
| VDR75100F/HF | VDR75100FW/HF | VDR75100FE/HF | VDR75100FB/HF | 75*100 | 8 | 12 | 24M |
| VDR80100F/HF | VDR80100FW/HF | VDR80100FE/HF | VDR80100FB/HF | 80*100 | 8 | 12 | 24M |
| VDR100100F/HF | VDR100100FW/HF | VDR100100FE/HF | VDR100100FB/HF | 100*100 | 8 | 12 | 24M |
| VDR120100F/HF | VDR120100FW/HF | VDR120100FE/HF | VDR120100FB/HF | 120*100 | 8 | 12 | 16M |
| VDR150100F/HF | VDR150100FW/HF | VDR150100FE/HF | VDR150100FB/HF | 150*100 | 8 | 12 | 16M |
| VDR160100F/HF | VDR160100FW/HF | VDR160100FE/HF | VDR160100FB/HF | 160*100 | 8 | 12 | / |
| VDR100130F/HF | VDR100130FW/HF | VDR100130FE/HF | VDR100130FB/HF | 100*130 | 8 | 12 | / |
| VDR200100F/HF | VDR200100FW/HF | VDR200100FE/HF | VDR200100FB/HF | 200*100 | 8 | 12 | 16M |
| VDR200150F/HF | VDR200150FW/HF | VDR200150FE/HF | VDR200150FB/HF | 200*150 | 8 | 12 | 16M |
