公制螺纹 M | 德制螺纹 PG | 美制螺纹 NPT | 英制螺纹 G | 适用电缆 Cable Range | 螺纹长度 ThreadLength L1 | 接合长度 Joint Length L2+L3 | 板手 Spanner SW A/F |
MGS12×1.5-6.5 | PGS7-6.5 | NPTS1/4-6.5 | GS1/4-6.5 | 3-6.5 | 6 | 18 | 15 |
MGS16×1.5-8 | PGS9-8 | 4-8 | 7 | 20 | 19 | ||
MGS18×1.5-10 | PGS11-10 | NPTS3/8-10 | GS3/8-10 | 6-10 | 8 | 21 | 21 |
MGS20×1.5-12 | PGS13.5-12 | NPTS1/2-12 | GS1/2-12 | 8-12 | 8 | 22 | 23 |
MGS22×1.5-14 | PGS16-14 | NPTS1/2-14 | GS1/2-14 | 10-14 | 9 | 23 | 25 |
MGS25×1.5-16 | 10-16 | 10 | 25 | 28 | |||
MGS25×1.5-18 | PGS21-18 | NPTS3/4-18 | GS3/4-18 | 13-18 | 11 | 25 | 30 |
MGS32×1.5-18 | 13-18 | 11 | 25 | 34 | |||
MGS32×1.5-22 | 16-22 | 11 | 26 | 36 | |||
MGS32×1.5-25 | PGS29-25 | NPTS1-25 | GS1-25 | 18-25 | 11 | 30 | 40 |
MGS36×1.5-25 | 18-25 | 11 | 30 | 40 | |||
MGS40×1.5-28 | 22-28 | 12 | 31 | 45 | |||
MGS40×1.5-32 | PGS36-32 | NPTS1-1/4-32 | GS1-1/4-32 | 22-32 | 13 | 35 | 55 |
MGS48×1.5-32 | 22-32 | 13 | 35 | 55 | |||
MGS50×1.5-36 | NPTS1-1/2-36 | GS1-1/2-36 | 28-36 | 13 | 38 | 55 | |
MGS54×1.5-38 | PGS42-38 | NPTS1-1/2-38 | GS1-1/2-38 | 32-38 | 13 | 38 | 60 |
MGS60×1.5-44 | PGS48-44 | NPTS2-44 | GS2-44 | 37-44 | 14 | 40 | 65 |
MGS63×1.5-44 | 37-44 | 14 | 40 | 70 | |||
MGS72×2.0-52 | 42-52 | 15 | 40 | 75 | |||
MGS80×2.0-60 | 55-60 | 20 | 40 | 90 | |||
MGS88×2.0-70 | 65-70 | 20 | 40 | 100 | |||
MGS100×2.0-80 | 70-80 | 20 | 40 | 110 | |||
MGS20×1.5-14 | 10-14 | 9 | 23 | 25 | |||
MGS24×1.5-16 | 10-16 | 10 | 25 | 28 | |||
MGS27×2.0-18 | 13-18 | 11 | 25 | 30 | |||
MGS30×2.0-18 | 13-18 | 11 | 25 | 34 | |||
MGS33×2.0-22 | 16-22 | 11 | 26 | 36 | |||
MGS42×2.0-30 | 22-30 | 12 | 31 | 45 |
